// -*- tab-width: 4; Mode: C++; c-basic-offset: 4; indent-tabs-mode: t -*- |
// |
// Interrupt-driven serial transmit/receive library. |
// |
// Copyright (c) 2010 Michael Smith. All rights reserved. |
// |
// Receive and baudrate calculations derived from the Arduino |
// HardwareSerial driver: |
// |
// Copyright (c) 2006 Nicholas Zambetti. All right reserved. |
// |
// Transmit algorithm inspired by work: |
// |
// Code Jose Julio and Jordi Munoz. DIYDrones.com |
// |
// This library is free software; you can redistribute it and/or |
// modify it under the terms of the GNU Lesser General Public |
// License as published by the Free Software Foundation; either |
// version 2.1 of the License, or (at your option) any later |
// version. |
// |
// This library is distributed in the hope that it will be |
// useful, but WITHOUT ANY WARRANTY; without even the implied |
// warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR |
// PURPOSE. See the GNU Lesser General Public License for more |
// details. |
// |
// You should have received a copy of the GNU Lesser General |
// Public License along with this library; if not, write to the |
// Free Software Foundation, Inc., 51 Franklin St, Fifth Floor, |
// Boston, MA 02110-1301 USA |
// |
// |
// Note that this library does not pre-declare drivers for serial |
// ports; the user must explicitly create drivers for the ports they |
// wish to use. This is less friendly than the stock Arduino driver, |
// but it saves a few bytes of RAM for every unused port and frees up |
// the vector for another driver (e.g. MSPIM on USARTs). |
// |
#ifndef FastSerial_h |
#defineFastSerial_h |
// disable the stock Arduino serial driver |
#ifdef HardwareSerial_h |
# error Must include FastSerial.h before the Arduino serial driver is defined. |
#endif |
#defineHardwareSerial_h |
#include<inttypes.h> |
#include<stdlib.h> |
#include<avr/io.h> |
#include<avr/interrupt.h> |
#include'BetterStream.h' |
/// @file FastSerial.h |
/// @brief An enhanced version of the Arduino HardwareSerial class |
/// implementing interrupt-driven transmission and flexible |
/// buffer management. |
/// |
/// Because Arduino libraries aren't really libraries, but we want to |
/// only define interrupt handlers for serial ports that are actually |
/// used, we have to force our users to define them using a macro. |
/// |
/// FastSerialPort(<port name>, <port number>) |
/// |
/// <port name> is the name of the object that will be created by the |
/// macro. <port number> is the 0-based number of the port that will |
/// be managed by the object. |
/// |
/// Previously ports were defined with a different macro for each port, |
/// and these macros are retained for compatibility: |
/// |
/// FastSerialPort0(<port name>) creates <port name> referencing serial port 0 |
/// FastSerialPort1(<port name>) creates <port name> referencing serial port 1 |
/// FastSerialPort2(<port name>) creates <port name> referencing serial port 2 |
/// FastSerialPort3(<port name>) creates <port name> referencing serial port 3 |
/// |
/// Note that compatibility macros are only defined for ports that |
/// exist on the target device. |
/// |
/// @name Compatibility |
/// |
/// Forward declarations for clients that want to assume that the |
/// default Serial* objects exist. |
/// |
/// Note that the application is responsible for ensuring that these |
/// actually get defined, otherwise Arduino will suck in the |
/// HardwareSerial library and linking will fail. |
//@{ |
externclassFastSerial Serial; |
externclassFastSerial Serial1; |
externclassFastSerial Serial2; |
externclassFastSerial Serial3; |
//@} |
/// The FastSerial class definition |
/// |
classFastSerial: publicBetterStream { |
public: |
/// Constructor |
FastSerial(constuint8_t portNumber, volatileuint8_t *ubrrh, volatileuint8_t *ubrrl, volatileuint8_t *ucsra, |
volatileuint8_t *ucsrb, constuint8_t u2x, constuint8_t portEnableBits, constuint8_t portTxBits); |
/// @name Serial API |
//@{ |
virtualvoidbegin(long baud); |
virtualvoidend(void); |
virtualintavailable(void); |
virtualinttxspace(void); |
virtualintread(void); |
virtualintpeek(void); |
virtualvoidflush(void); |
#if defined(ARDUINO) && ARDUINO >= 100 |
virtualsize_twrite(uint8_t c); |
#else |
virtualvoidwrite(uint8_t c); |
#endif |
using BetterStream::write; |
//@} |
/// Extended port open method |
/// |
/// Allows for both opening with specified buffer sizes, and re-opening |
/// to adjust a subset of the port's settings. |
/// |
/// @note Buffer sizes greater than ::_max_buffer_size will be rounded |
/// down. |
/// |
/// @param baud Selects the speed that the port will be |
/// configured to. If zero, the port speed is left |
/// unchanged. |
/// @param rxSpace Sets the receive buffer size for the port. If zero |
/// then the buffer size is left unchanged if the port |
/// is open, or set to ::_default_rx_buffer_size if it is |
/// currently closed. |
/// @param txSpace Sets the transmit buffer size for the port. If zero |
/// then the buffer size is left unchanged if the port |
/// is open, or set to ::_default_tx_buffer_size if it |
/// is currently closed. |
/// |
virtualvoidbegin(long baud, unsignedint rxSpace, unsignedint txSpace); |
/// Transmit/receive buffer descriptor. |
/// |
/// Public so the interrupt handlers can see it |
structBuffer { |
volatileuint16_t head, tail; ///< head and tail pointers |
uint16_t mask; ///< buffer size mask for pointer wrap |
uint8_t *bytes; ///< pointer to allocated buffer |
}; |
/// Tell if the serial port has been initialized |
staticboolgetInitialized(uint8_t port) { |
return (1<<port) & _serialInitialized; |
} |
// ask for writes to be blocking or non-blocking |
voidset_blocking_writes(bool blocking) { |
_nonblocking_writes = !blocking; |
} |
private: |
/// Bit mask for initialized ports |
staticuint8_t _serialInitialized; |
/// Set if the serial port has been initialized |
staticvoidsetInitialized(uint8_t port) { |
_serialInitialized = (1<<port); |
} |
// register accessors |
volatileuint8_t * const _ubrrh; |
volatileuint8_t * const _ubrrl; |
volatileuint8_t * const _ucsra; |
volatileuint8_t * const _ucsrb; |
// register magic numbers |
constuint8_t _u2x; |
constuint8_t _portEnableBits; ///< rx, tx and rx interrupt enables |
constuint8_t _portTxBits; ///< tx data and completion interrupt enables |
// ring buffers |
Buffer * const _rxBuffer; |
Buffer * const _txBuffer; |
bool _open; |
// whether writes to the port should block waiting |
// for enough space to appear |
bool _nonblocking_writes; |
/// Allocates a buffer of the given size |
/// |
/// @param buffer The buffer descriptor for which the buffer will |
/// will be allocated. |
/// @param size The desired buffer size. |
/// @returns True if the buffer was allocated successfully. |
/// |
staticbool_allocBuffer(Buffer *buffer, unsignedint size); |
/// Frees the allocated buffer in a descriptor |
/// |
/// @param buffer The descriptor whose buffer should be freed. |
/// |
staticvoid_freeBuffer(Buffer *buffer); |
/// default receive buffer size |
staticconstunsignedint _default_rx_buffer_size = 128; |
/// default transmit buffer size |
staticconstunsignedint _default_tx_buffer_size = 16; |
/// maxium tx/rx buffer size |
/// @note if we could bring the max size down to 256, the mask and head/tail |
/// pointers in the buffer could become uint8_t. |
/// |
staticconstunsignedint _max_buffer_size = 512; |
}; |
// Used by the per-port interrupt vectors |
extern FastSerial::Buffer __FastSerial__rxBuffer[]; |
extern FastSerial::Buffer __FastSerial__txBuffer[]; |
/// Generic Rx/Tx vectors for a serial port - needs to know magic numbers |
/// |
#defineFastSerialHandler(_PORT, _RXVECTOR, _TXVECTOR, _UDR, _UCSRB, _TXBITS) |
ISR(_RXVECTOR, ISR_BLOCK) |
{ |
uint8_t c; |
uint16_t i; |
/* read the byte as quickly as possible */ |
c = _UDR; |
/* work out where the head will go next */ |
i = (__FastSerial__rxBuffer[_PORT].head + 1) & __FastSerial__rxBuffer[_PORT].mask; |
/* decide whether we have space for another byte */ |
if (i != __FastSerial__rxBuffer[_PORT].tail) { |
/* we do, move the head */ |
__FastSerial__rxBuffer[_PORT].bytes[__FastSerial__rxBuffer[_PORT].head] = c; |
__FastSerial__rxBuffer[_PORT].head = i; |
} |
} |
ISR(_TXVECTOR, ISR_BLOCK) |
{ |
/* if there is another character to send */ |
if (__FastSerial__txBuffer[_PORT].tail != __FastSerial__txBuffer[_PORT].head) { |
_UDR = __FastSerial__txBuffer[_PORT].bytes[__FastSerial__txBuffer[_PORT].tail]; |
/* increment the tail */ |
__FastSerial__txBuffer[_PORT].tail = |
(__FastSerial__txBuffer[_PORT].tail + 1) & __FastSerial__txBuffer[_PORT].mask; |
} else { |
/* there are no more bytes to send, disable the interrupt */ |
if (__FastSerial__txBuffer[_PORT].head __FastSerial__txBuffer[_PORT].tail) |
_UCSRB &= ~_TXBITS; |
} |
} |
structhack |
// |
// Portability; convert various older sets of defines for U(S)ART0 up |
// to match the definitions for the 1280 and later devices. |
// |
#if !defined(USART0_RX_vect) |
# if defined(USART_RX_vect) |
# defineUSART0_RX_vect USART_RX_vect |
# defineUSART0_UDRE_vect USART_UDRE_vect |
# elif defined(UART0_RX_vect) |
# defineUSART0_RX_vect UART0_RX_vect |
# defineUSART0_UDRE_vect UART0_UDRE_vect |
# endif |
#endif |
#if !defined(USART1_RX_vect) |
# if defined(UART1_RX_vect) |
# defineUSART1_RX_vect UART1_RX_vect |
# defineUSART1_UDRE_vect UART1_UDRE_vect |
# endif |
#endif |
#if !defined(UDR0) |
# if defined(UDR) |
# defineUDR0 UDR |
# defineUBRR0H UBRRH |
# defineUBRR0L UBRRL |
# defineUCSR0A UCSRA |
# defineUCSR0B UCSRB |
# defineU2X0 U2X |
# defineRXEN0 RXEN |
# defineTXEN0 TXEN |
# defineRXCIE0 RXCIE |
# defineUDRIE0 UDRIE |
# endif |
#endif |
/// |
/// Macro defining a FastSerial port instance. |
/// |
#defineFastSerialPort(_name, _num) |
FastSerial _name(_num, |
&UBRR##_num##H, |
&UBRR##_num##L, |
&UCSR##_num##A, |
&UCSR##_num##B, |
U2X##_num, |
(_BV(RXEN##_num) _BV(TXEN##_num) _BV(RXCIE##_num)), |
(_BV(UDRIE##_num))); |
FastSerialHandler(_num, |
USART##_num##_RX_vect, |
USART##_num##_UDRE_vect, |
UDR##_num, |
UCSR##_num##B, |
_BV(UDRIE##_num)) |
/// |
/// Compatibility macros for previous FastSerial versions. |
/// |
/// Note that these are not conditionally defined, as the errors |
/// generated when using these macros for a board that does not support |
/// the port are better than the errors generated for a macro that's not |
/// defined at all. |
/// |
#defineFastSerialPort0(_portName) FastSerialPort(_portName, 0) |
#defineFastSerialPort1(_portName) FastSerialPort(_portName, 1) |
#defineFastSerialPort2(_portName) FastSerialPort(_portName, 2) |
#defineFastSerialPort3(_portName) FastSerialPort(_portName, 3) |
#endif // FastSerial_h |
